Production capacity for Vannamei shrimp, tilapia, catfish, and other species with a total intensive area of 20 hectares. Located in Chiná-Chulbac, Campeche.
Technical data for Chulbac:
Number and types of ponds:
10 nursery ponds (pre-cría)
20 grow-out ponds (engorda)
Pond dimensions and average depth:
10 nursery ponds: Total nursery area 12,000 m² (distance between axes 40x36 m), hydraulic area (1,200 m²), average dike height 1.80 m, average water column depth 1.40 m.
20 grow-out ponds: Total grow-out area 140,000 m² (distance between axes 42x182 m), hydraulic area (7,000 m²), average dike height 1.70 m, average water column depth 1.30 m.
Available aeration equipment (horsepower and type of aerator).
Water alkalinity analysis required (mg/L or ppm) — last recorded value was 2 ppm.
Available facilities: warehouses, offices, laboratory, etc.
Pump capacity from the well (liters/second): 100 L/s with a 10-inch vertical submersible pump (horsepower of motor to be verified).
Re-pumping capacity: 30 L/s with a 6-inch pump (if installed).
Re-pumping volume based on water surface area: Lagoon of 40 x 360 x 1.0 m = 14,400 m³. This would be 10% of the grow-out ponds, provided water quality in the sedimentation lagoon is improved with probiotics.
Percentage of water renewal available in 24 hours: 8,000 m³ per 24 hours of pumping; 100% renewal for one grow-out pond and 5% for all 20 grow-out ponds.
Installed capacity of electric power plants (kVA).CUENTA CON CAPACIDAD DE PRODUCCIÓN DE CAMARÓN VANNAMEI, TILAPIA BAGRE Y OTRAS ESPECIES, CON UNA SUPERFICIE TOTAL DE 20 HECTÁREAS INTENSIVAS. UBICADO EN CHINÁ- CHULBAC, CAMPECHE.
DATOS TECNICOS CHULBAC:
1.- NUMERO DE ESTANQUES Y TIPOS: 10 ESTANQUES DE PRECRIA Y 20 ESTANQUES DE ENGORDA.
2.- DIMENSIONES DE LOS ESTANQUES CON PROFUNDIDAD PROMEDIO: 10 ESTANQUES DE PRECRIA. AREA TOTAL DE PRECRIA 12,000 M2 (DISTANCIA A EJES 40X36, AREA HIDRAULICA (1,200M2), ALTURA DE BORDO PROMEDIO 1.80 MTS, PROFUNDIDAD COLUMNA DE AGUA PROMEDI0 1.40 MTS) Y 20 ESTANQUES DE ENGORDA. AREA TOTAL DE ENGORDA 140,000 M2 (DISTANCIA A EJES 42X182, AREA HIDRAULICA (7,000M2), ALTURA DE BORDO PROMEDIO 1.70 MTS Y PROFUNDIDAD COLUMNA DE AGUA PROMEDIO 1.30 MTS.
3.- EQUIPO DE AIREACION DISPONOBLE (HP Y TIPO DE AIREADOR)
4.- SE REQUIERE ANALISIS DE ALCALINIDAD DEL AGUA EN MG/L O PPM (SEGÚN LO ULTIMO QUE MANEJARON FUERON 2 PPM)
5.- INSTALACIONES DISPONIBLES BODEGAS, OFICINAS, LABORATORIO, ETC.
6.- CAPACIDAD DE BOMBEO DE LAS BOMBAS DEL POZO (LT / SEG) Y 100LTS / SEG, CON BOMBA VERTICAL SUMERGIBLE DE 10 PULGADAS (FALTA VERFICAR LOS HP DEL MOTOR)
7.- CAPACIDAD DE REBOMBEO: 30 LTS / SEG CON BOMBA DE 6”. (SI SE INSTALA)
8.- VOLUMEN DE REBOMBEO EN FUNCION DEL ESPEJO DE AGUA: LAGUNA DE 40 X 360 X 1.0 = 14,400 M3. SERIA UN 10 % DE LOS ESTANQUES DE ENGORDA SIEMPRE Y CUANDO SE MEJORE LA CALIDAD DEL AGUA DE LA LAGUNA DE SEDIMENTACION CON PROBIOTICOS.
9.- PORCENTAJE DE RECAMBIO DISPONIBLE EN 24 HORAS: 8000 M3 POR 24 HORAS DE BOMBEO, 100 % DE UN ESTANQUE DE ENGORDA Y 5 % DE LOS 20 ESTANQUES DE ENGORDA.
10.- CAPACIDAD INSTALADA DE LAS PLANTAS DE ENERGIA ELECTRICA (KVA).
ENG:
Production capacity for Vannamei shrimp, tilapia, catfish, and other species with a total intensive area of 20 hectares. Located in Chiná-Chulbac, Campeche.
Technical data for Chulbac:
Number and types of ponds:
10 nursery ponds (pre-cría)
20 grow-out ponds (engorda)
Pond dimensions and average depth:
10 nursery ponds: Total nursery area 12,000 m² (distance between axes 40x36 m), hydraulic area (1,200 m²), average dike height 1.80 m, average water column depth 1.40 m.
20 grow-out ponds: Total grow-out area 140,000 m² (distance between axes 42x182 m), hydraulic area (7,000 m²), average dike height 1.70 m, average water column depth 1.30 m.
Available aeration equipment (horsepower and type of aerator).
Water alkalinity analysis required (mg/L or ppm) — last recorded value was 2 ppm.
Available facilities: warehouses, offices, laboratory, etc.
Pump capacity from the well (liters/second): 100 L/s with a 10-inch vertical submersible pump (horsepower of motor to be verified).
Re-pumping capacity: 30 L/s with a 6-inch pump (if installed).
Re-pumping volume based on water surface area: Lagoon of 40 x 360 x 1.0 m = 14,400 m³. This would be 10% of the grow-out ponds, provided water quality in the sedimentation lagoon is improved with probiotics.
Percentage of water renewal available in 24 hours: 8,000 m³ per 24 hours of pumping; 100% renewal for one grow-out pond and 5% for all 20 grow-out ponds.
Installed capacity of electric power plants (kVA).
